Description
The Armstrong Fluid Technology E30.2 circulator pump (MPN 182212-645) delivers reliable, efficient fluid circulation for a wide range of residential and light commercial applications — including hydronic heating, cooling, and snow melt systems. Built from heavy-duty cast iron and powered by a 2/5 HP single-phase motor, this pump is engineered to perform consistently in demanding environments while keeping energy consumption low.
A stainless steel shaft and permanently lubricated bearings ensure long-term, low-maintenance operation, while the bellows-style mechanical seal with silicon carbide wear surface provides exceptional durability and leak resistance. Its compact footprint makes it easy to install even in tight mechanical spaces, and its quiet, low-vibration operation contributes to a more comfortable building environment.
Product Highlights
- Quiet, low-vibration operation for improved occupant comfort
- Stainless steel shaft and permanently lubricated bearings for sustained, maintenance-free performance
- Bellows-style mechanical seal with silicon carbide wear surface for enhanced durability and leak protection
- Compact design ideal for space-constrained installations
- Precise flow control to meet the demands of diverse hydronic applications
- Suitable for heating, cooling, and snow melt systems in residential and light commercial settings
Specifications
- Brand: Armstrong Fluid Technology
- MPN: 182212-645
- Motor Power: 2/5 HP
- Voltage: 120V, Single-Phase
- Maximum Temperature: 230°F
- Maximum Working Pressure: 150 PSI
- Flow Rate: Up to 140 GPM
- Head: Up to 60 ft.
- Body Material: Cast Iron
- Shaft Material: Stainless Steel
