Description
The ASCO 8210G12 is a pilot-operated, 2-way normally open solenoid valve engineered for dependable general service fluid control in commercial and industrial HVAC applications. With a robust brass body and NBR seals, this valve is built to handle air, water, and light oil service across a wide operating pressure range.
Key Features
- 2-way, normally open (N/O) configuration — valve opens when de-energized, closes when energized
- Pilot-operated design for efficient, low-power actuation
- 1/2″ NPT port connection for straightforward installation into standard piping systems
- 120VAC coil voltage for compatibility with common commercial power supplies
- 4 Cv flow coefficient for reliable media throughput
- Brass body construction for corrosion resistance and long service life
- NBR (Buna-N) seals for compatibility with air, water, and light oil media
- NEMA 4X enclosure rating — suitable for indoor and outdoor use, including washdown and corrosive environments
Operating Specifications
- Voltage: 120VAC
- Port Size: 1/2″ NPT
- Flow Coefficient (Cv): 4
- Air Pressure Range: 5–250 PSI
- Water & Light Oil Pressure Range: 5–200 PSI
- Valve Action: Normally Open (N/O)
- Operation Type: Pilot Operated
- Body Material: Brass
- Seal Material: NBR (Buna-N)
- Enclosure Rating: NEMA 4X
Applications
- HVAC air and water control systems
- Light oil service lines
- General-purpose industrial fluid control
- Outdoor or wash-down environments requiring NEMA 4X protection
- Automated process control and building automation systems
The ASCO 8210G12 delivers the reliability and versatility that HVAC professionals and industrial technicians demand. Its NEMA 4X-rated enclosure ensures protection against dust, splashing water, and corrosion, making it equally at home in mechanical rooms or outdoor installations. Trust ASCO’s proven solenoid valve technology for consistent, long-term performance in your critical fluid control applications.
