Description
Belimo 22PF-5UHH Overview
The Belimo 22PF-5UHH is a 2″ NPT pressure-independent flow meter engineered for accurate, real-time flow measurement in commercial and industrial hydronic HVAC systems. Rated for up to 91.2 GPM and operating on a 24V power supply, this flow meter delivers reliable performance in demanding building automation and energy management applications.
Key Features
- 2″ NPT pipe connection for straightforward installation in standard hydronic piping
- Maximum flow rate of 91.2 GPM for medium-to-large commercial hydronic systems
- 24V operating voltage — compatible with standard BAS/DDC control systems
- Pressure-independent design ensures accurate flow measurement regardless of system pressure fluctuations
- Compact, robust construction suitable for commercial HVAC and building automation environments
- Enables precise energy monitoring and system balancing
- Designed for integration with Belimo actuators and control systems
Applications
- Commercial hydronic heating and cooling systems
- Building automation and energy management systems
- Chilled water and hot water distribution loops
- Flow balancing and commissioning of HVAC systems
Product Specifications
- Model: 22PF-5UHH
- Brand: Belimo
- Connection Size: 2″ NPT
- Maximum Flow Rate: 91.2 GPM
- Supply Voltage: 24V
