Description
The Century H1042L is a rugged, industrial-grade three-phase motor engineered for demanding HVAC and commercial applications. Built on the versatile 56CZ C-Face frame, this motor mounts directly to pumps, fans, and other driven equipment, eliminating the need for a separate coupling or base adapter in most installations.
Key Specifications
- Horsepower: 3/4 HP
- Speed: 1725 RPM
- Voltage: 208-230/460 VAC
- Phase: Three Phase
- Frame: 56CZ
- Service Factor: 1.50
- Bearings: Ball Bearings
- Overload Protector: None
- Rotation: RCC (Reversible, Clockwise/Counter-Clockwise)
- Mounting: C-Face
- Enclosure: Dripproof (ODP)
Performance & Design Highlights
The H1042L’s 1.50 service factor provides a built-in performance cushion, allowing the motor to handle temporary overload conditions without overheating or premature failure. Ball bearings deliver smooth, low-friction operation and extended service life, even in continuous-duty environments. The open dripproof (ODP) enclosure protects internal windings from dripping liquids and falling debris in non-hazardous indoor locations, while still allowing adequate airflow for efficient cooling.
Flexible Voltage & Reversible Rotation
Dual-voltage capability (208-230/460 VAC) makes the H1042L easy to wire into a wide range of three-phase electrical systems without the need for additional transformers or adapters. Reversible rotation (RCC) gives technicians the flexibility to configure the motor for clockwise or counter-clockwise shaft rotation to suit the specific requirements of the driven load.
Ideal Applications
- HVAC fans and blowers
- Pumps and compressors
- Commercial refrigeration equipment
- General-purpose industrial machinery
- Direct-drive C-Face mounted equipment
Why Choose the Century H1042L?
Century Motors has a long-standing reputation for producing reliable, high-efficiency motors built to meet the rigorous demands of HVAC and industrial professionals. The H1042L combines proven motor technology with a flexible design, making it a dependable drop-in solution for a wide variety of replacement and new-installation applications.
