Description
The Conbraco 94-MBV-02 is a rugged, compact ¼″ mini ball valve (male NPT × female NPT) from Apollo / Conbraco, designed for precision flow control in tight spaces. Built from forged brass with a full-port design, this heavy-pattern valve delivers reliable performance for water, oil, or gas applications in commercial and light-industrial systems.
Key Features
- Compact & Versatile: ¼″ MNPT × ¼″ FNPT connection makes it ideal for instrumentation, gauge cock, or test cock use.
- Heavy-Pattern Brass Body: Forged brass construction offers long-lasting strength and reliability.
- Blow-Out Proof Stem: Designed to resist stem ejection for enhanced safety even under pressure.
- Double Viton O-Rings: Provides excellent sealing performance and resistance to leaks.
- Chrome-Plated Brass Ball: Ensures smooth operation and corrosion resistance.
- Reversible Lever Handle: Allows for flexible installation and easy operation.
- High Pressure Capacity: Rated for up to 600 psi WOG (water, oil, gas) at 100 °F.
- Wide Temperature Range: Operates reliably from –40 °F to +300 °F.
- ANSI/MSS Standards: Built to meet MSS-SP-110 and ASME B16.44.
