Description
The Copeland 047504 is a direct acting, 2-way normally closed refrigeration solenoid valve body designed for reliable flow control in commercial and light commercial refrigeration systems. Featuring a 3/8″ sweat connection, this valve body provides a leak-tight, brazed installation that is ideal for professional HVAC/R technicians. The normally closed design ensures the valve remains shut in the de-energized state, providing a critical safety function that prevents refrigerant flow during power loss or system shutdown.
Refrigerant Capacity
- R22 Capacity: 1.27 Ton
- R134a Capacity: 1.20 Ton
Key Features
- 2-Way, Normally Closed (NC) operation — valve closes automatically when de-energized
- Direct acting design — no minimum pressure differential required to open or close
- 3/8″ sweat (ODF) connection for secure brazed installation
- Valve body only — compatible with standard Copeland/industry solenoid coils (coil sold separately)
- Engineered for use with R22 and R134a refrigerants
- Suitable for liquid line, suction line, and hot gas bypass applications in refrigeration systems
- Compact, rugged construction for dependable long-term performance
Specifications
- SKU: 047504
- Model / Part Number: 100RB2S3
- Brand: Copeland
- Valve Type: 2-Way Normally Closed Solenoid Valve Body
- Operation: Direct Acting
- Connection Size: 3/8″
- Connection Type: Sweat (ODF)
- R22 Rated Capacity: 1.27 Ton
- R134a Rated Capacity: 1.20 Ton
Applications
- Commercial refrigeration liquid line control
- Suction line pump-down circuits
- Hot gas defrost and bypass systems
- Light commercial air conditioning refrigerant circuit control
