Description
Copeland STAS4811SV Suction Line Filter Drier
The Copeland STAS4811SV (SKU 053938) is a heavy-duty steel suction line filter drier engineered to protect refrigeration and air conditioning systems from moisture, acid, and contaminants on the suction side of the circuit. With a robust steel shell and a generous 48 cubic inch capacity, this filter drier is built for demanding commercial and industrial HVAC/R applications where system reliability is non-negotiable.
Key Features
- 1-3/8″ ODF (sweat) connection for straightforward field installation
- 48 cubic inch shell volume for high-capacity moisture and contaminant removal
- Single-core design — core sold separately, allowing field selection of the appropriate desiccant core
- 680 PSI maximum working pressure for compatibility with a wide range of refrigerants and high-pressure systems
- Durable steel construction for long service life in demanding environments
- Suction line configuration protects the compressor from harmful moisture, acid, and debris
Product Specifications
- SKU: 053938
- Model: STAS4811SV
- Brand: Copeland
- Connection Size: 1-3/8″ ODF (Sweat)
- Shell Volume: 48 cubic inches
- Core: Single core (not included)
- Maximum Working Pressure: 680 PSI
- Shell Material: Steel
- Application: Suction line
Application & Installation Notes
Designed for installation on the suction line upstream of the compressor, the STAS4811SV helps prevent compressor damage caused by moisture, acid, and particulate contamination — especially critical during system changeouts, burnout cleanups, or new installations. The shell-and-core design allows technicians to select and replace the desiccant core independently, reducing long-term maintenance costs. Always braze connections using nitrogen purge procedures and follow Copeland installation guidelines for best results.
