Copeland 057233 Automatic Thermal Expansion Valve (TXV) 1/4″ x 3/8″ ODF

Description

The Copeland 057233 is a precision-engineered Automatic Thermal Expansion Valve (TXV) designed for reliable refrigerant flow control in a wide range of HVAC and refrigeration applications. Featuring a straight-body design with sweat (ODF) connections and an internal equalizer, this valve delivers consistent superheat management and system efficiency.

Key Features

• Automatic Thermal Expansion Valve (TXV) for precise refrigerant metering
• 1/4″ inlet x 3/8″ ODF (sweat) outlet connections
• Straight body configuration for straightforward installation
• Internal equalizer design — no external equalizer line required
• 0.05″ port diameter for accurate flow control
• Fully adjustable pressure range: 0–80 psig
• Factory set at 40 psig for out-of-the-box convenience

Product Specifications

• Model: ACP 1 IE 1/4 x 3/8 ODF S/T
• SKU: 057233
• Connection Type: Sweat (ODF)
• Inlet Size: 1/4″
• Outlet Size: 3/8″
• Body Style: Straight
• Equalizer Type: Internal
• Port Diameter: 0.05″
• Adjustable Range: 0–80 psig
• Factory Pressure Setting: 40 psig

Application

The Copeland 057233 TXV is ideal for use in air conditioning and refrigeration systems where controlled superheat is critical to compressor protection and system performance. The internal equalizer design simplifies installation in systems with low pressure drop across the evaporator, while the fully adjustable pressure setting allows technicians to fine-tune operation to match specific system requirements.
