Description
Schneider Electric (Erie) VT2222G13B020 Two-Way Normally Closed Zone Valve
The Schneider Electric (Erie) VT2222G13B020 is a two-way, normally closed, spring return zone valve assembly engineered for precise two-position flow control in hydronic heating and cooling systems. Designed for dependable zone isolation, this valve delivers consistent performance in residential and light commercial HVAC applications where reliable on/off control is essential.
Key Specifications
- Configuration: Two-Way, Normally Closed (NC)
- Connection Size: 1/2″ NPT
- Flow Coefficient: 2.5 Cv
- Voltage: 120VAC
- Actuator Type: Spring Return
- Control Action: Two-Position (On/Off)
- SKU / Part Number: VT2222G13B020
- Brand: Schneider Electric (Erie)
Product Features & Benefits
- Normally closed design ensures the valve defaults to the closed (safe) position upon loss of power, protecting the system from unintended flow
- Spring return actuator provides reliable, automatic valve closure when the control signal is removed — no manual reset required
- 1/2″ NPT connections offer straightforward installation compatibility with standard hydronic piping
- 2.5 Cv flow coefficient is optimized for low-flow zone applications, delivering accurate and efficient fluid control
- 120VAC operation integrates seamlessly with standard residential and commercial control wiring
- Two-position (open/close) control simplifies zone management and reduces system complexity
- Compact valve assembly design allows installation in tight mechanical spaces
- Built to Erie’s proven quality standards under the Schneider Electric portfolio, trusted by HVAC professionals worldwide
Typical Applications
- Hydronic heating zone control
- Radiant floor heating systems
- Fan coil unit water flow control
- Chilled water cooling coil isolation
- Multi-zone boiler systems
- Residential and light commercial HVAC zoning
The Erie VT2222G13B020 zone valve assembly is a trusted solution for contractors and engineers who demand reliable, code-compliant flow control in zoned hydronic systems. Its spring return, normally closed design provides built-in fail-safe protection, while the 120VAC actuator ensures compatibility with the widest range of zone controllers and thermostats.
