Description
The Functional Devices RIBT243P is a 3PST-N/O is an enclosed relay with hi/low seperation. The RIBT243P is a 20 amp 24Vac/dc coil relay that has an expected relay life of 10 million cycles minimum.
Functional Devices RIBT243P Enclosed 20Amp Power Control Relay
$89.73
MSRP: $169.29
You save 47%
20 Amp 24 Vac/dc Power Control Relay
Availability:
Ships By January 22
Additional information
| Contact Type | 3PST |
|---|---|
| Resistance | 20 Amp |
| Wires | 16", 600V Rated |
| Dimensions | 4" x 4" x 1.8" with .50" NPT Nipple |
| Operating Temperature | -30?F to 140?F |
| Humidity Range | 5 to 95% (noncondensing) |
| Operate Time | 20ms |
| Relays with Contact Type | One (1) 3PST Continuous Duty Coil |
| Relay Status | LED On = Activated |
| Override Switch | No |
| Gold Flash | No |
| Expected Relay Life | 10 million cycles minimum mechanical |
| Coil Current | 210 mA @ 24 VAC 154 mA @ 30 VDC |
| Coil Voltage Input | 24V AC/DC ; 50-60 Hz Drop Out = 3 VAC / 3.8 VDC Pull In = 20 VAC / 22 VDC |
| Voltage | 24V AC/DC |
