Description
The Functional Devices RIBTW2402B-BC is a BACnet-enabled enclosed relay designed for seamless integration into building automation systems. Featuring high/low voltage separation for added safety and a robust 20-amp SPDT switching capacity, this relay is built to handle demanding commercial HVAC control applications with confidence.
Key Features
- BACnet communication protocol for direct integration with building automation systems
- High/low voltage separation for enhanced electrical safety
- 20-amp SPDT relay for reliable load switching
- Wide coil voltage range: 24Vac/dc and 208–277Vac
- 1 digital input for monitoring or control feedback
- Enclosed housing for protection and ease of installation
Specifications
- SKU: RIBTW2402B-BC
- Brand: Functional Devices
- Communication Protocol: BACnet
- Relay Type: SPDT (Single Pole Double Throw)
- Relay Rating: 20 Amps
- Coil Voltage: 24Vac/dc / 208–277Vac
- Voltage Separation: High/Low
- Digital Inputs: 1
- Enclosure: Enclosed
