Description
The Honeywell V5013C1027 is a heavy-duty 3-way diverting globe valve engineered for commercial and industrial hydronic systems. With a robust cast iron body and bronze trim, this valve delivers reliable, long-service performance in demanding chilled water and hot water applications.
Key Features
- 3-way diverting configuration — stem up increases flow from port AB to port A
- 4″ pipe size with 125# flange end connections for easy integration into large hydronic systems
- High flow capacity with a Cv rating of 160 for minimal pressure drop
- Linear (constant total) flow characteristic for precise, proportional control
- Cast iron body with bronze trim for excellent corrosion resistance and durability
- Compatible with chilled water and hot water systems containing up to 50% glycol
- Maximum working pressure of 150 PSI for safe, reliable operation
Specifications
- SKU: V5013C1027
- Brand: Honeywell
- Valve Type: Globe, 3-Way Diverting
- Pipe Size: 4″
- End Connection: 125# Flange
- Cv Rating: 160
- Flow Characteristic: Linear (Constant Total)
- Body Material: Cast Iron
- Trim Material: Bronze
- Stem Action: Stem Up to Increase Flow (AB to A)
- Maximum Working Pressure: 150 PSI
- Fluid Compatibility: Chilled water, hot water, up to 50% glycol
Applications
- Commercial and industrial chilled water systems
- Hot water heating and distribution systems
- Hydronic HVAC systems requiring precise 3-way diverting control
- Glycol-based fluid systems (up to 50% concentration)
- Large-scale building automation and temperature control systems
