Description
The Lau 60560701 is a heavy-duty condenser style fan blade engineered for demanding HVAC applications where consistent, reliable airflow is critical. Designed with an 18-inch diameter and a 33-degree blade pitch, this five-blade assembly delivers optimized static pressure performance and efficient air movement across condenser coils.
Key Features
- 18″ overall blade diameter for broad airflow coverage
- 33° blade pitch for optimized condenser airflow efficiency
- 5-blade design for balanced, smooth air delivery
- Clockwise (CW) rotation for proper condenser discharge direction
- Interchangeable hub design for versatile installation compatibility
- Heavy-duty construction built to withstand continuous outdoor operation
- Condenser style configuration for use in air-cooled condensing units
Application
The Lau 60560701 is ideal for replacement or OEM applications in residential and light commercial air-cooled condensing units, heat pumps, and rooftop equipment. The interchangeable hub allows for straightforward installation across a variety of motor shaft configurations, reducing downtime and simplifying service calls.
Product Specifications
- Brand: Lau
- SKU: 60560701
- Blade Diameter: 18″
- Blade Pitch: 33°
- Number of Blades: 5
- Rotation: Clockwise (CW)
- Hub Type: Interchangeable
- Duty Rating: Heavy Duty
- Style: Condenser
