Description
The Maid O’Mist Model 71 Minipeeper is a compact ultraviolet (UV) flame detector engineered for reliable flame sensing on coal, gas, and oil fired burners. Designed for demanding combustion environments, this detector provides accurate and responsive UV-based flame detection to support safe burner operation and flame safeguard control systems.
Key Features
- Ultraviolet (UV) flame detection technology for accurate, reliable sensing
- Compatible with coal, gas, and oil fired burners
- 96-inch (8 ft) lead length for flexible installation and routing
- Wide ambient temperature range: -40°F to 215°F for use in extreme environments
- Mounts directly on 1/2-inch sighting pipe via an integral collar for secure, precise positioning
- Includes 1/2-inch NPT spud connector for straightforward installation
- Compact Minipeeper form factor for installations with limited space
Specifications
- Model: 71 (Minipeeper)
- Detection Type: Ultraviolet (UV) Flame Detector
- Compatible Fuels: Coal, Gas, Oil
- Lead Length: 96 inches
- Ambient Temperature Range: -40°F to 215°F
- Sighting Pipe Size: 1/2 inch
- Mounting: Integral collar on 1/2-inch sighting pipe
- Connection: 1/2-inch NPT spud connector (included)
Applications
- Commercial and industrial boiler burner systems
- Coal, gas, and oil fired combustion equipment
- Flame safeguard and burner management control systems
- Retrofit and replacement installations on existing sighting pipe assemblies
The Model 71 Minipeeper is built to integrate seamlessly with flame safeguard controls, delivering dependable UV flame signal output across a broad operating temperature range. Its included NPT spud connector and integral collar mounting simplify installation, making it a practical choice for both new installations and field replacements.
