Description
The Manitowoc Ice 000007926 (LGP-G) is a manual reset, single-pole double-throw (SPDT) low gas pressure switch engineered to protect gas-fired equipment from unsafe low-pressure conditions. With a sensing range of 1–20″ water column (“wc) and a rugged NEMA 4 enclosure, this switch is built for demanding commercial and industrial HVAC applications where moisture resistance and reliable shutoff are critical.
Key Features
- Pressure sensing range: 1–20″ water column (“wc)
- Manual reset operation — requires deliberate technician action before restart, preventing automatic re-ignition after a low-pressure fault
- SPDT (Single-Pole Double-Throw) switching action for flexible circuit integration
- 1/4″ NPT process connection for straightforward installation into standard gas lines
- NEMA 4 rated enclosure — provides protection against windblown dust, rain, splashing water, and hose-directed water
- OEM part number LGP-G for direct Manitowoc Ice equipment compatibility
Application
Designed as a safety interlock on gas-fired commercial equipment, the LGP-G monitors supply gas pressure and opens the circuit when pressure drops below the set point. The manual reset requirement ensures a qualified technician investigates and resolves the root cause before the system is returned to service, reducing the risk of unsafe operation.
Specifications
- SKU: 000007926
- OEM Model: LGP-G
- Switch Type: SPDT, Manual Reset
- Pressure Range: 1–20″ wc
- Connection: 1/4″ NPT
- Enclosure Rating: NEMA 4
- Brand: Manitowoc Ice
