Mars 80315 Condenser Fan Motor Overview
The Mars 80315 is a dependable permanent split capacitor (PSC) condenser fan motor engineered for reliable performance in residential and light commercial HVAC condensing units. Built to industry-standard 42 NEMA frame specifications, this motor is a trusted choice for replacement and OEM applications alike.
Key Specifications
- Horsepower: 1/5 HP
- Voltage: 208–230 VAC
- Phase: Single Phase
- Speed: 1,075 RPM
- Number of Speeds: 1
- Full Load Amps: 1.08 A
- NEMA Frame Size: 42
- Bearing Type: Sleeve Bearing
- Mount Type: Thru Bolt
- Rotation: Clockwise (CW)
- Motor Type: Permanent Split Capacitor (PSC)
Design & Construction
The sleeve bearing design provides quiet, smooth operation and long service life in condenser fan applications. The thru bolt mounting configuration simplifies installation and ensures a secure fit in a wide range of condensing unit housings. The 42 NEMA frame ensures broad cross-reference compatibility with many OEM condenser fan motor applications.
Application
Ideal for use in residential and light commercial air conditioning condensing units requiring a single-phase, single-speed condenser fan motor. The 208–230V operating voltage makes it compatible with standard residential and commercial power supplies.
Why Choose Mars Motors?
- Industry-proven PSC motor technology for efficient, reliable operation
- Standard 42 NEMA frame for broad OEM cross-reference compatibility
- Sleeve bearing construction for quiet, long-lasting performance
- Thru bolt mount for straightforward field installation
- Clockwise rotation as viewed from the shaft end
