Description
Panasonic Ventilation S-600 Atmosphere Corded Mixed-Flow In-line Fan
The Panasonic Ventilation S-600 Atmosphere is a high-performance corded mixed-flow in-line fan engineered for reliable, efficient ventilation in residential and light commercial applications. Designed to move air quietly and effectively through a 6″ duct connection, the S-600 delivers an impressive 312 CFM at 0.2 inches of static pressure — making it an ideal choice for bathrooms, kitchens, utility rooms, and other spaces requiring dependable exhaust ventilation.
Key Features
- Mixed-flow in-line design for efficient, high-volume air movement
- 312 CFM airflow capacity at 0.2″ static pressure
- 6″ duct connection for straightforward installation into existing ductwork
- Sealed casing construction minimizes air leakage and maximizes system efficiency
- Compact form factor fits easily in tight ceiling or wall cavities
- Backdraft damper included to prevent reverse airflow when the fan is off
- Speed controller available separately for customizable airflow adjustment
- Corded design for simple electrical connection
Design & Installation
The S-600’s sealed casing ensures that conditioned air stays where it belongs, reducing energy waste and improving overall system performance. Its compact footprint simplifies retrofits and new installations alike, while the included backdraft damper provides an added layer of protection against unwanted air infiltration. For applications requiring variable airflow, a compatible speed controller is available separately, giving installers and end users precise control over ventilation rates.
Applications
- Residential bathroom and kitchen exhaust ventilation
- Utility and laundry room ventilation
- Light commercial exhaust and supply air systems
- In-line duct ventilation where space is limited
Specifications
- Model: S-600
- Airflow: 312 CFM at 0.2″ static pressure
- Duct Size: 6″
- Fan Type: Mixed-Flow In-line
- Casing: Sealed
- Backdraft Damper: Included
- Speed Controller: Available separately
- Power: Corded
