Description
The Parker-Sporlan 101905 is a heavy-duty, two-way normally open actuated ball valve engineered for demanding HVAC and hydronic control applications. Built around a forged brass body with stainless steel trim, this 3-inch valve delivers reliable two-position flow control with a 74 Cv equal percentage flow characteristic — ideal for precise modulation in chilled water, hot water, and condenser water systems.
Powered by a spring-return actuator rated for both 24 VAC and 24 VDC operation, the valve automatically returns to its normally open (fail-safe open) position upon loss of power, protecting system integrity. The ASME Class 150 flanged end connections ensure compatibility with standard piping systems and simplify installation in commercial and industrial settings. Two built-in SPDT auxiliary switches provide end-of-travel position feedback for integration with building automation systems, DDC controllers, and safety interlock circuits.
Key Features
- Two-way, normally open (fail-safe open) configuration
- 3-inch pipe size with ASME Class 150 flange end connections
- 74 Cv flow coefficient with equal percentage flow characteristic
- Dual voltage actuator: 24 VAC / 24 VDC compatible
- Spring-return, two-position actuator for reliable fail-safe operation
- Forged brass valve body for durability and corrosion resistance
- Stainless steel trim for long service life in wet and aggressive media
- Two built-in SPDT auxiliary switches for position feedback and BAS integration
Specifications
- SKU: 101905
- Brand: Parker-Sporlan
- Valve Type: 2-Way Ball Valve
- Valve Action: Normally Open (Spring Return)
- Pipe Size: 3 inch
- End Connection: ASME Class 150 Flange
- Flow Coefficient (Cv): 74
- Flow Characteristic: Equal Percentage
- Actuator Voltage: 24 VAC / 24 VDC
- Actuator Type: Spring Return, Two-Position
- Body Material: Forged Brass
- Trim Material: Stainless Steel
- Auxiliary Switches: 2 x SPDT
Applications
- Chilled water and hot water distribution systems
- Condenser water and cooling tower circuits
- Commercial HVAC air handling units and fan coils
- Building automation and DDC control systems
- Industrial process fluid control
