Description
The Schneider Electric (Barber Colman) 2372-502 Pneumodular High Pressure Selector is a precision-engineered pneumatic control component designed for commercial and industrial HVAC building automation systems. Part of the trusted Pneumodular series, this selector reliably routes the higher of two pneumatic input signals to a single output — a critical function in dual-duct, mixed-air, and other pressure-priority control strategies.
Built to perform in demanding pneumatic control environments, the 2372-502 features a compact, modular design that integrates seamlessly into existing Barber Colman/Schneider Electric pneumatic control panels and systems.
Key Specifications
- Main Air Operating Pressure: 20 PSIG
- Air Capacity: 8 SCFH
- Connections: Barbed nipples compatible with 1/4″ O.D. or 5/32″ I.D. tubing
- Series: Pneumodular
- Brand: Schneider Electric (Barber Colman)
- SKU: 2372-502
Features & Benefits
- High pressure selector function automatically passes the higher of two pneumatic signals to the output
- Pneumodular design allows for easy integration and modular panel assembly
- Barbed nipple fittings provide secure, leak-resistant tubing connections
- Compatible with standard 1/4″ O.D. or 5/32″ I.D. pneumatic tubing for flexible installation
- Compact form factor minimizes panel space requirements
- Reliable performance in commercial building automation and HVAC pneumatic control systems
Applications
- Dual-duct HVAC systems requiring high-signal selection
- Commercial building automation pneumatic control panels
- Mixed-air and pressure-priority control strategies
- Retrofit and replacement in existing Barber Colman Pneumodular installations
