Description
The Schneider Electric (Square D) LC1D115B7 is a heavy-duty, non-reversing IEC contactor engineered for demanding electrical and HVAC applications. With a robust 115-amp rating and a 24VAC control coil, this contactor delivers reliable switching performance in commercial and industrial systems including large motor loads, compressors, and HVAC equipment.
Key Features
- 24VAC control coil for compatibility with standard HVAC and industrial control circuits
- 3-pole configuration for three-phase load switching
- 115-amp continuous current rating for heavy-duty applications
- Non-reversing design for straightforward motor and load control
- Screw terminal connections for secure, code-compliant wiring
- One normally closed (NC) auxiliary contact included
- One normally open (NO) auxiliary contact included
- Part of the Schneider Electric TeSys D contactor family
Auxiliary Contacts
The LC1D115B7 includes a built-in auxiliary contact block featuring one normally open (NO) and one normally closed (NC) contact. These auxiliary contacts are ideal for interlocking, signaling, and control circuit applications, providing added flexibility in panel design and system integration.
Applications
- Large commercial HVAC compressor and motor control
- Three-phase motor starting and stopping
- Industrial machinery and equipment control panels
- Pump and fan motor switching
- Building automation and energy management systems
Why Choose Schneider Electric (Square D)?
Schneider Electric’s TeSys D series contactors are globally recognized for their reliability, long electrical life, and ease of installation. The LC1D115B7 is built to IEC standards, ensuring consistent performance and compatibility with international electrical systems. Screw terminals simplify field wiring, and the compact footprint supports efficient panel layouts.
