Jackson Systems

SPDT Relay for Handy Box Mounting 24 Vac W/Track

BRAND: iO HVAC Controls SKU: RY-1-HB

$18.85

MSRP: $21.68
You save 15%

SPDT Relay for Handy Box Mounting

Availability:

Ships By February 22

Description

RY-1-HB Handy Relay 2.75 in. Track Mount Relay –  15 Amp SPDT with 24 Vac/dc Coil

Relays can be used in numerous applications.  All components are wave soldered to a printed circuit board and snap track mounted. This is a single pole, double throw relay designed for general purpose.



Features and Benefits



  • 10 amp contacts with 24 volt AC/DC
  • LED indicates when relay is energized
  • Angled terminal strips for easy wiring
  • Snap track mounting included
  • Handy box mounting reduces enclosure cost (optional)
  • 1-year warranty

Additional information

Coil Draw

14 mA

Contact Type

SPDT

Dimensions

0.875" x 2.50"

Input Voltage

24v

Relay Type

Electro mechanical

Contact Rating

10 Amp @120 V, 6 Amp @277 V

UPC 840119926583
