Description
The Sprecher + Schuh R15-2012-235120WTL is a compact, high-quality general purpose relay engineered for dependable switching performance in HVAC, building automation, and industrial control applications. Featuring a double-pole double-throw (DPDT) configuration on an 8-pin base, this relay delivers versatile circuit switching with a 10-amp contact rating and a 120VAC coil voltage — making it a natural fit for standard North American control panel installations.
An integrated LED indicator provides instant visual confirmation of relay energization, simplifying troubleshooting and commissioning directly at the panel without additional test equipment.
Key Features
- DPDT (Double-Pole Double-Throw) contact configuration for versatile switching
- 8-pin octal base design for easy socket mounting and field replacement
- 10A contact current rating for reliable load switching
- 120VAC coil voltage — compatible with standard North American control circuits
- Built-in LED indicator for instant visual status confirmation
- Compact form factor ideal for control panels and enclosures
Specifications
- Brand: Sprecher + Schuh
- Model / SKU: R15-2012-235120WTL
- Contact Configuration: DPDT (2 Form C)
- Pin Configuration: 8-Pin Octal
- Contact Rating: 10A
- Coil Voltage: 120VAC
- Indicator: LED
Typical Applications
- HVAC control panels and building automation systems
- Fan, pump, and motor switching circuits
- Industrial and commercial control enclosures
- Zone control and sequencing applications
