Trane SWT3017 SPST High-Limit Switch Overview
The Trane SWT3017 is a Single Pole Single Throw (SPST) high-limit safety switch engineered to protect HVAC equipment from dangerous overtemperature conditions. Designed as a direct OEM replacement for compatible Trane systems, this switch automatically interrupts the circuit when temperatures reach unsafe levels, then resets once conditions return to a safe range.
How It Works
The SWT3017 monitors system temperature continuously. When the sensed temperature rises to the trip point, the switch opens to cut power and prevent equipment damage or fire hazard. Once the system cools to the reset threshold, the switch closes and normal operation resumes.
Key Specifications
- SKU / Part Number: SWT3017
- Switch Type: SPST (Single Pole Single Throw)
- Function: High-Limit Safety Switch
- Opening (Trip) Temperature: 650°F
- Closing (Reset) Temperature: 550°F
- Brand: Trane
Features & Benefits
- Automatic reset at 550°F for convenient, reliable operation
- Opens at 650°F to guard against overheating and equipment damage
- SPST design for straightforward circuit integration
- OEM Trane part — ensures proper fit and performance in compatible systems
- Provides a critical layer of safety in heating and HVAC applications
Applications
- Trane commercial and residential HVAC systems
- Furnaces and air handlers requiring high-temperature limit protection
- Any compatible system requiring an OEM Trane high-limit switch replacement
