Overview
The US Motors 5860 is a reliable Bourdon tube pressure switch engineered for general-purpose HVAC and industrial pressure monitoring applications. With a wide 5 to 150 Psig operating range and a 24 Psig adjustable deadband, this switch delivers precise, repeatable pressure control across a broad spectrum of system demands. Its rugged brass tube construction and general-purpose enclosure make it well suited for demanding mechanical room environments.
Key Features
- Bourdon tube sensing element for accurate, long-lasting pressure detection
- 5 to 150 Psig operating range for versatile system compatibility
- 24 Psig adjustable deadband for customizable switching differential
- SPDT (Single-Pole, Double-Throw) switching action supports both normally open and normally closed circuit configurations
- Brass tube material for corrosion resistance and durability
- 10 Amp electrical rating for reliable load switching
- General-purpose enclosure suitable for standard mechanical and utility installations
- 1/4″ Male NPT process connection for easy integration into existing piping systems
- Vertical mounting orientation for flexible installation
Specifications
- Brand: US Motors
- SKU: 5860
- Switch Type: Bourdon Tube Pressure Switch
- Operating Range: 5 to 150 Psig
- Adjustable Deadband: 24 Psig
- Switch Action: SPDT
- Tube Material: Brass
- Electrical Rating: 10 Amp
- Enclosure Type: General Purpose
- Process Connection: 1/4″ Male NPT
- Mounting: Vertical
Applications
Ideal for use in HVAC systems, hydronic heating and cooling circuits, compressor protection, and general industrial pressure monitoring where a dependable, field-adjustable pressure switch is required.
