US Motors D2P2H General Purpose Motor Overview
The US Motors D2P2H is a dependable general purpose motor engineered for demanding HVAC and industrial applications. Delivering 2 horsepower at 200 volts AC on a three-phase power supply, this motor runs at 1740 RPM and draws 6.4 amps — providing efficient, consistent performance across a wide range of equipment. Its reversible rotation capability adds installation flexibility, making it suitable for a variety of system configurations.
Key Specifications
- Horsepower: 2 HP
- Voltage: 200 Vac
- Phase: Three Phase
- Speed: 1740 RPM (1 Speed)
- Full Load Amps: 6.4 Amps
- NEMA Frame Size: 145T
- Enclosure Type: Open Drip Proof (ODP)
- Bearing Type: Ball Bearing
- Mount Type: Rigid Mount
- Rotation: Reversible
Design & Construction
The 145T NEMA frame ensures straightforward drop-in replacement compatibility with standard motor mounts. The Open Drip Proof (ODP) enclosure protects internal components from dripping liquids and falling debris in semi-protected environments, while still allowing adequate ventilation for efficient heat dissipation. Precision ball bearings provide smooth, low-friction operation and extended service life, reducing maintenance intervals and downtime.
Application Versatility
With reversible rotation and a rigid mount design, the D2P2H adapts easily to fans, blowers, pumps, compressors, and other HVAC or light industrial equipment. The three-phase, 200 Vac power configuration is ideal for commercial and light industrial installations where three-phase power is available.
Why Choose US Motors
US Motors (a Nidec brand) is a trusted name in the HVAC and industrial motor industry, known for quality engineering, reliable performance, and broad application coverage. The D2P2H continues that tradition, offering a robust general purpose motor built to perform in real-world conditions.
