Description
The Century FDL6002 is a heavy-duty permanent split capacitor (PSC) air over motor engineered for reliable, continuous-duty performance in demanding HVAC applications. Rated at 3/4 horsepower and designed for use in air-over environments, this motor delivers consistent airflow-cooled operation ideal for evaporator fan and condenser fan assemblies.
Electrical Specifications
- Voltage: 115V AC, Single Phase
- Amperage: 9.1 Amps
- Motor Type: Permanent Split Capacitor (PSC)
Mechanical Specifications
- Horsepower: 3/4 HP
- Speed: 1075 RPM
- Frame: 48
- Motor Diameter: 5-5/8″
- Bearings: Ball Bearings
- Enclosure: Open Drip-Proof (ODP)
- Rotation: Reversible
- Duty: Continuous Duty Air Over
- Protector: Auto Protector
Key Features & Benefits
- Permanent split capacitor design provides smooth, efficient starting and running performance
- Ball bearing construction ensures long service life and reduced maintenance
- Open drip-proof enclosure protects internal components from dripping liquids in standard HVAC environments
- Reversible rotation offers installation flexibility for a wide range of fan and blower configurations
- Auto protector provides built-in thermal overload protection, safeguarding the motor against overheating
- Continuous duty air over rating makes it ideal for applications where the motor is cooled by the airstream it drives
- 48 frame standard ensures broad compatibility with OEM and replacement applications
Typical Applications
- Evaporator fan motors in refrigeration and HVAC systems
- Condenser fan assemblies
- Air handling unit fan drives
- Commercial refrigeration equipment
