Description
The Century D1056 is a heavy-duty Permanent Split Capacitor (PSC) condenser fan motor engineered for reliable continuous air-over applications in residential and light commercial HVAC systems. With its open construction and versatile mounting options, this motor is a go-to direct replacement for a wide range of condenser fan assemblies.
Electrical Specifications
- Voltage: 208–230V AC
- Amperage: 3.2–4.3 Amps
- Motor Type: Permanent Split Capacitor (PSC)
- Speeds: 3-Speed
Mechanical Specifications
- Horsepower: 1/2 HP
- RPM: 1075
- Frame Diameter: 5-5/8″
- Bearing Type: Sleeve Bearings
- Construction: Open
- Duty: Continuous Air Over (CAO)
Features & Accessories
- Auto thermal protector for motor safety
- Lead reversible for flexible installation
- 26″ leads for easy wiring reach
- Includes 2-1/4″ mounting rings with 2-1/2″ adapter rings
Applications
The D1056 is designed for continuous air-over duty, making it ideal for use in condenser fan applications on central air conditioning systems, heat pumps, and other HVAC equipment. The open construction promotes airflow through the motor, and the included mounting ring adapters allow for broad cross-reference compatibility across multiple OEM platforms.
Why Choose the Century D1056?
- Versatile 3-speed operation for flexible system matching
- Auto protector safeguards against overheating
- Lead reversible design simplifies rotation changes without rewiring
- Sleeve bearings provide quiet, dependable operation
- Mounting adapters included for fast, hassle-free installation
