Description
The Century 9210H is a high-efficiency ECM (Electronically Commutated Motor) designed for demanding HVAC blower and fan applications. Its multi-horsepower flexibility — rated at 1/15 HP, 1/20 HP, and 1/25 HP — makes it a versatile replacement motor suitable for a wide range of residential and light commercial air-handling equipment.
Key Features
- ECM technology for improved energy efficiency and quiet operation compared to traditional PSC motors
- Multi-horsepower rating: 1/15 HP, 1/20 HP, and 1/25 HP
- Operating speed: 1550 RPM
- Voltage: 230V
- Rotation: Clockwise (CW) viewed from shaft end
- Mounting: 4 stud mounting configuration for secure, vibration-resistant installation
- Lead length: 13 inches for flexible wiring connections
Why Choose an ECM Motor?
ECM motors use a permanent magnet rotor and electronic commutation to deliver superior efficiency over conventional induction motors. This translates to lower operating costs, reduced heat generation, and longer service life — making the Century 9210H an excellent choice for energy-conscious HVAC installations and replacements.
Typical Applications
- Residential and light commercial air handlers
- Furnace blower assemblies
- Fan coil units
- HVAC equipment requiring low-horsepower, high-efficiency motor replacement
Specifications
- SKU: 9210H
- Brand: Century
- Motor Type: ECM (Electronically Commutated Motor)
- Horsepower: 1/15 HP / 1/20 HP / 1/25 HP
- Speed: 1550 RPM
- Voltage: 230V
- Rotation: Clockwise (CW) — Shaft End
- Mounting: 4 Stud
- Lead Length: 13 inches
