Description
Overview
The Century ARB2034L6 is a heavy-duty belt drive motor engineered for reliable performance in demanding HVAC and commercial air-handling applications. Built on a 48 frame platform with a totally enclosed air over (TEAO) design, this motor delivers consistent airflow-cooled operation in belt-driven fan and blower systems where durability and longevity are critical.
Electrical Specifications
- Horsepower: 1/3 HP
- Voltage: 115/208-230V AC
- Phase: Single Phase
- Amperage: 4.9A (115V) / 2.3–2.5A (208-230V)
- Speed: 1725 RPM
- Number of Speeds: 1
- Motor Type: Split Phase
Mechanical Specifications
- Frame Size: 48
- Enclosure: Totally Enclosed Air Over (TEAO)
- Bearing Type: Ball Bearing
- Shaft Diameter: 5/8″
- Rotation: Reversible
- Mounting: Resilient Base
Key Features
- Totally Enclosed Air Over (TEAO) enclosure protects internal components from dust, debris, and moisture in airstream environments
- Ball bearing construction provides long service life and reduced maintenance requirements
- Reversible rotation offers installation flexibility for a wide range of belt drive fan and blower configurations
- Dual voltage capability (115/208-230V) simplifies installation across varying electrical supply configurations
- Resilient base mounting reduces vibration transmission and noise for quieter system operation
- 5/8″ diameter shaft accommodates standard belt drive pulleys and sheaves
- 1725 RPM synchronous speed suits a broad range of HVAC fan and blower applications
- Split phase motor design provides reliable starting performance in single-phase power environments
Applications
The Century ARB2034L6 is ideal for use in belt drive fan coil units, air handlers, evaporative coolers, and commercial ventilation systems where a compact, durable, and versatile single-phase motor is required.
