Description
The ASCO 8360G71 is a direct-acting, 3-way universal solenoid valve engineered for reliable general service applications involving air and water. Built with a durable plastic body and an NBR (Buna-N) seal, this valve delivers dependable shutoff and flow control across a wide range of commercial and industrial HVAC systems.
Key Features
- 3-way universal configuration for versatile installation and flow-path flexibility
- Direct-acting design — operates without minimum pressure differential, ensuring reliable performance at 0 PSI
- 1/4″ OD compression fitting connection for quick, leak-free installation
- 120VAC coil voltage for compatibility with standard commercial control circuits
- Flow coefficient (Cv) of 0.07 for precise, low-flow control
- Rated for 0–100 PSI operating pressure range
- Compatible with air and water media
- NBR (Nitrile Buna-N) seal material for excellent resistance to water and air service
- Plastic body construction — lightweight and corrosion-resistant
- NEMA 4X enclosure rating — suitable for indoor and outdoor use, resistant to dust, splashing water, and corrosion
Specifications
- SKU: 8360G71
- Brand: ASCO
- Valve Type: 3-Way Universal, Direct Acting
- Connection: 1/4″ OD Compression
- Voltage: 120VAC
- Flow Coefficient (Cv): 0.07
- Pressure Range: 0–100 PSI
- Media: Air and Water
- Body Material: Plastic
- Seal Material: NBR (Nitrile Buna-N)
- Enclosure Rating: NEMA 4X
Applications
- HVAC control systems requiring precise air or water flow switching
- General service fluid control in commercial and light industrial environments
- Pneumatic and hydraulic control circuits
- Outdoor or wash-down environments where NEMA 4X protection is required
