Description
Enhance safety and reliability in your gas-fired equipment with the BASO Gas Products H43BB-2 automatic pilot valve. Built for commercial and industrial applications, this high-temperature version of the H43 series offers a compact solution for pilot burner control with manual shut-off capability.
Key Features:
- Automatic pilot shut-off with manual handle: This valve design combines a pilot and main burner safety shut-off into a single unit—gas flows to the pilot during start-up, and if the pilot flame fails, the main burner and pilot supply are both cut off.
- High-temperature rated (H43_B version): Built to handle ambient surface temperatures up to 250 °F (0 to 121 °C) for the “B” variant, making it suitable for harsher environments.
- Rated for up to 0.5 psi (35 mbar) inlet pressure: Compatible with standard low-pressure natural gas or LP systems.
- ½″ NPT body connection size: Fits ½-inch NPT inlet/outlet piping common in many commercial furnaces and burners.
- Supports Natural Gas, LP Gas, and LP-air mixtures: Flexible for use across multiple fuel types.
- Compact design: Dimensions make it suitable for installations where space is limited.
