Description
The Belimo SGVL+SVKB24-SR is a factory-matched globe valve and actuator assembly engineered for precise, proportional flow control in commercial HVAC hydronic systems. Combining the SGVL globe valve body with the SVKB24-SR linear actuator, this integrated assembly delivers reliable modulating performance in heating and cooling applications.
Key Features
- Factory-matched SGVL globe valve body and SVKB24-SR linear actuator combination
- 24V AC/DC power supply for broad system compatibility
- 337 lbf (approximately 1,500 N) close-off force for positive shutoff against system pressure
- 2–10 VDC proportional control signal for precise, modulating flow regulation
- Designed for hydronic heating and cooling coil applications in commercial HVAC systems
- Compact, integrated design simplifies installation and reduces field assembly time
- Belimo’s proven actuator technology ensures long service life and reliable operation
Specifications
- SKU: SGVL+SVKB24-SR
- Brand: Belimo
- Supply Voltage: 24V AC/DC
- Actuator Force: 337 lbf
- Control Signal: 2–10 VDC (proportional/modulating)
- Valve Type: Globe valve
- Actuator Type: Linear (SVKB series)
Application
The SGVL+SVKB24-SR is ideal for use in variable air volume (VAV) systems, fan coil units, air handling units, and other commercial HVAC hydronic applications requiring accurate flow modulation. The 2–10 VDC input signal allows seamless integration with building automation systems (BAS) and direct digital controls (DDC), enabling energy-efficient zone-level temperature management.
