Description
The Conbraco Industries 20-601-00 is a heavy-duty rough bronze water gauge engineered for reliable visual water level and pressure monitoring in demanding hydronic and steam system applications. Built with quality materials throughout, this gauge delivers long-lasting performance across a wide range of operating conditions.
Key Features
- 1/2″ NPT male connections for straightforward installation into standard piping systems
- 5/8″ OD x 12″ length standard glass for a clear, wide viewing area
- Rough bronze body construction for superior corrosion resistance and durability
- EPDM glass seal provides excellent resistance to heat, steam, and chemical exposure
- Teflon stem packing ensures a leak-free seal and smooth operation over time
- Chain operation for safe, convenient gauge glass isolation and blowdown
Pressure & Temperature Ratings
- Rated at 500 PSI @ 100°F
- Rated at 250 PSI @ 400°F
Applications
- Boiler water level monitoring
- Hydronic heating systems
- Steam system sight glass applications
- Industrial process fluid level indication
Specifications
- SKU: 20-601-00
- Brand: Conbraco Industries
- Connection Size: 1/2″ NPT Male
- Glass OD: 5/8″
- Glass Length: 12″
- Glass Type: Standard
- Body Material: Rough Bronze
- Glass Seal Material: EPDM
- Stem Packing: Teflon
- Operation: Chain
- Max Pressure @ 100°F: 500 PSI
- Max Pressure @ 400°F: 250 PSI
