Description
The Conbraco Industries 25-501-00 is a high-performance polished bronze water gauge engineered for demanding hydronic and steam system applications. Featuring 1/2″ NPT male connections and a 5/8″ OD x 12″ standard glass sight tube, this gauge delivers clear, reliable water level visibility in boilers and pressure vessels.
Key Features
- Polished bronze body construction for corrosion resistance and long service life
- 1/2″ NPT male connections for straightforward installation on standard pipe fittings
- 5/8″ OD x 12″ length standard glass sight tube for excellent water level visibility
- Automatic ball checks provide automatic shut-off if the glass breaks, enhancing safety
- EPDM glass seal for superior temperature and chemical resistance
- PTFE with Hypalon stem packing for reliable, leak-free valve performance
- Aluminum type handwheel for easy manual operation
Pressure & Temperature Ratings
- Rated at 200 PSI @ 400°F
- Rated at 400 PSI (saturated steam conditions)
Specifications
- SKU: 25-501-00
- Brand: Conbraco Industries
- Connection Size: 1/2″ NPT Male
- Glass OD: 5/8″
- Glass Length: 12″
- Glass Type: Standard
- Body Material: Polished Bronze
- Seal Material: EPDM
- Stem Packing: PTFE with Hypalon
- Handwheel: Aluminum Type
Applications
- Boiler water level monitoring
- Hydronic heating systems
- Steam pressure vessels
- Industrial process equipment requiring visual water level indication
