Copeland 1609-105 Temperature Control -30/90°F 5′ Cap Close-on-Rise w/ Knob

Description

Copeland 1609-105 Capillary Temperature Control

The Copeland 1609-105 is a capillary-type temperature control designed for precise high-limit temperature management in refrigeration and HVAC applications. Featuring a close-on-rise action, this control activates when the sensed temperature rises to the setpoint — making it ideal for high-limit cutout and safety control duties. The 5-foot capillary tube provides flexible remote sensing capability, allowing the sensing bulb to be positioned accurately at the point of measurement.

Key Features

• Temperature range: -30°F to 90°F
• 5-foot capillary tube for remote bulb sensing
• Close-on-rise (high-limit) switching action
• Manual adjustment knob for easy setpoint changes
• Compact design suitable for panel or equipment mounting
• Reliable capillary sensing for accurate temperature response

Application

This temperature control is well-suited for refrigeration systems, coolers, freezers, and HVAC equipment where high-limit temperature protection is required. The close-on-rise action ensures the control circuit responds appropriately when temperatures exceed the desired setpoint, providing a critical layer of equipment protection.

Specifications

• Brand: Copeland
• Part Number: 1609-105
• Temperature Range: -30°F to 90°F
• Capillary Length: 5 feet
• Action: Close on Rise (High Limit)
• Adjustment: Manual knob
