Description
The Honeywell Analytics Sensepoint XCL (SPLCC1BAXCXNZZ) is a professional-grade fixed gas detector engineered for continuous Carbon Monoxide (CO) monitoring in commercial and industrial environments. Combining robust construction with modern connectivity, this detector delivers reliable, accurate gas detection where safety is paramount.
Operating on 24Vac or 24Vdc power, the Sensepoint XCL integrates seamlessly into existing building automation and life-safety systems via its industry-standard 4-20mA analog output. The built-in Bluetooth interface enables wireless commissioning, configuration, and diagnostics — reducing setup time and improving technician safety by eliminating the need to open the enclosure in hazardous areas.
Key Features
- Detects Carbon Monoxide (CO) across a 50–1000ppm measurement range
- Dual-voltage supply: 24Vac or 24Vdc for flexible installation
- 4-20mA analog output for direct integration with BAS, PLCs, and controllers
- Integrated Bluetooth interface for wireless configuration and diagnostics
- IP65 ingress protection rating — dust-tight and protected against water jets
- Charcoal polycarbonate casing for durability and chemical resistance
- Fixed installation design for permanent, continuous gas monitoring
Detection Specifications
- Target Gas: Carbon Monoxide (CO)
- Measurement Range: 50–1000 ppm
- Output Signal: 4-20mA analog
- Power Supply: 24Vac / 24Vdc
Construction & Protection
- Enclosure Rating: IP65 (IEC 60529)
- Casing Material: Charcoal polycarbonate
- Connectivity: Bluetooth wireless interface
- Detector Type: Fixed (permanent installation)
Applications
- Commercial buildings and parking garages
- Industrial facilities and manufacturing plants
- Boiler rooms and mechanical equipment rooms
- Tunnels, warehouses, and confined spaces
- Any environment requiring continuous CO monitoring per life-safety codes
The Sensepoint XCL’s IP65-rated charcoal polycarbonate enclosure stands up to demanding indoor and semi-outdoor environments, while the Bluetooth interface allows technicians to commission and verify the detector using a smartphone or tablet — no wiring or enclosure access required during setup. This detector is an ideal solution for facilities managers, contractors, and engineers who need dependable fixed-point CO detection with modern connectivity and straightforward system integration.
