Description
The Honeywell M6184D1035 is a high-performance Modutrol IV three-wire floating control electric actuator engineered for precise control of valves and dampers. Designed for robust commercial HVAC and building automation systems, it delivers reliable modulation with a wide adjustable stroke and consistent torque.
Features:
- Integral junction box provides NEMA 3 weather protection if motor is mounted in the upright position.
- Motor and circuitry operate from 24 Vac.
- Quick-connect terminals are standard–screw terminal adapter is available.
- Adapter bracket for matching shaft height of older motors is available.
- Motors have field adjustable stroke (90 to 160 degrees).
- Integral auxiliary switches are available factory mounted, or can be field added.
- All models have dual shafts (slotted and tapped on both ends).
- All models have auxiliary switch cams.
- Fixed torque throughout the entire voltage range.
- Motors are designed for either normally open or normally closed valves and dampers.
