Description
The Honeywell MP958A1009 is a direct-acting pneumatic valve actuator engineered for reliable, precise control in commercial HVAC and building automation systems. Designed with a low actuator force profile and a spring return mechanism, this actuator delivers consistent valve positioning and automatic failsafe operation when air pressure is lost.
Key Features
- 2–5 PSI spring range for accurate, responsive valve modulation
- Direct acting operation — actuator extends as control pressure increases
- Spring return design ensures automatic failsafe positioning on loss of signal
- Low actuator force for compatibility with light-duty valve bodies
- Barbed fitting designed for 1/4″ OD plastic tubing — quick, tool-free pneumatic connections
- 30 PSI maximum operating pressure for safe, reliable performance
Compatible Valve Series
- V5852A2xxx
- V5862A2xxx
- V5853A2xxx
- V5863 series
Specifications
- SKU: MP958A1009
- Brand: Honeywell
- Actuator Type: Pneumatic, Direct Acting
- Spring Range: 2–5 PSI
- Return Type: Spring Return
- Maximum Operating Pressure: 30 PSI
- Tubing Connection: Barbed fitting for 1/4″ OD plastic tubing
The MP958A1009 is an ideal replacement or upgrade actuator for VAV, fan coil, and air handling unit valve assemblies in commercial and light industrial HVAC applications. Its straightforward pneumatic interface and spring return failsafe make it a dependable choice for building automation and energy management systems.
