Description
The Honeywell R7849B1013 is a solid‑state, plug‑in ultraviolet (UV) flame amplifier engineered for seamless integration with 7800 Series relay modules. Featuring Dynamic Ampli‑Check self‑test functionality, this module provides reliable flame validation and automatic safety lockout in the event of flame detection failure. It supports popular UV Minipeeper sensors—making it an essential for gas and oil burner safety systems.
Features:
- Flame failure response time of 0.8 or 3.0 seconds.
- Flame signal strength ranges from 0.0 to 5.0 Vdc.
- Plug into 7800 relay module through printed circuit board edge connector keyed for proper orientation.
- Flame signal test jacks to measure amplifier flame signal voltage.
- Color-coded labels identify flame detection type. Dynamic Self-Check Amplifier test the detectors and all electronic components in the flame detection system 7800 SERIES relay module locks out on safety shutdown with flame detection system failure.
- Compatible with existing Honeywell flame detectors (order separately).
- Type: Ultraviolet
- Flame Failure Response Time (sec): 0.8 sec or 1.0 sec
- Self Checking: Ampli-Check
- Use With Primary Safety Control: 7800 SERIES Relay Modules
- Use With Flame Sensor: Gas, Oil: Minipeeper C7027A, C7035A, C7044
