Honeywell VGF31EM60 6″ Flanged Mixing Valve, ANSI 125, Cv=400, Equal %

Description

Honeywell VGF31EM60 6″ Flanged Mixing Valve Overview

The Honeywell VGF31EM60 is a heavy-duty 6-inch flanged three-way mixing valve engineered for demanding commercial and industrial hydronic heating and cooling applications. With an ANSI 125 flange rating and a high flow coefficient of Cv=400, this valve is designed to handle high-volume fluid flow with precision and reliability. The equal percentage flow characteristic ensures smooth, stable modulating control across the full range of valve travel, making it an ideal choice for large-scale HVAC systems requiring accurate temperature regulation.

Key Features

• 6-inch flanged body for secure, leak-free pipe connections
• ANSI 125 flange rating for compatibility with standard commercial piping systems
• High flow coefficient of Cv=400 for large-volume hydronic applications
• Equal percentage (EQ%) flow characteristic for precise, stable modulating control
• Three-way mixing configuration for blending supply and return water streams
• Designed for use with compatible Honeywell actuators for automated control
• Robust construction suited for commercial and industrial HVAC environments

Typical Applications

• Large commercial hydronic heating and cooling systems
• Building automation and energy management systems
• Central plant temperature control and distribution
• Industrial process heating and cooling loops

Specifications

• SKU: VGF31EM60
• Brand: Honeywell
• Valve Size: 6 inches
• Connection Type: Flanged (ANSI 125)
• Valve Type: Three-Way Mixing
• Flow Coefficient (Cv): 400
• Flow Characteristic: Equal Percentage (EQ%)
