Description
The IDEC RSSDN-25A is a robust, high-reliability solid-state relay designed for switching substantial AC loads (~25 A) under control of a DC logic signal (3-32 V DC). Its zero-voltage switching, photo-isolation, built-in transient suppression and compact panel-mount packaging make it well suited for modern industrial control systems where long life, low maintenance, and silent operation are required.
Features:
-
Control (input) voltage: 3 – 32 V DC.
-
Load (output) rating: 25 A continuous current.
-
Output voltage range: 48 – 660 V AC.
-
Contact form: 1 Form A (Single-pole, single-throw, normally open).
-
Zero voltage switching type – helps reduce switching noise/inrush.
-
Photo-isolation (input to output isolation) of 4,000 V RMS minimum.
-
Built-in transient suppression (snubber) and high surge capability.
