Description
The International Comfort Products 1014028 is a direct-replacement blower motor engineered for reliable air-handling performance in residential and light-commercial HVAC systems. Built to OEM specifications, this motor delivers consistent airflow across four selectable speeds, making it well-suited for multi-stage heating and cooling applications.
Electrical Specifications
- Voltage: 115V AC
- Phase: Single Phase
- Horsepower: 1/2 HP
- Amperage: 7.2 Amps
- Motor Type: Permanent Split Capacitor (PSC)
Mechanical Specifications
- Speed: 1100 RPM, 4-Speed
- NEMA Frame Size: 48
- Bearing Type: Sleeve Bearing
- Mounting Style: Band Mount
- Rotation: Counter-Clockwise (CCW)
Key Features & Benefits
- Permanent Split Capacitor design for smooth, energy-efficient operation
- Four selectable speed taps allow precise airflow matching to system requirements
- 48 NEMA frame ensures broad compatibility with standard blower housings
- Sleeve bearing construction provides quiet, low-maintenance performance
- Band mount design simplifies installation and secure positioning within the blower assembly
- Counter-clockwise rotation matches OEM blower wheel orientation for drop-in replacement
- Single-phase 115V AC power suits standard residential electrical supply
Application
Designed as an OEM replacement for International Comfort Products air handlers and furnaces, the 1014028 blower motor restores original system performance quickly and reliably. Its band-mount configuration and standard 48 NEMA frame make installation straightforward for qualified HVAC technicians. The PSC motor type ensures efficient, low-noise operation throughout the full range of heating and cooling cycles.
