Description
The Johnson Controls DP110100U3V4V is a precision pressure transducer engineered for demanding HVAC and building automation applications. Featuring a 0–100 pressure range with a standard 4–20 mA analog output signal, this transducer delivers accurate, repeatable pressure measurements that integrate seamlessly with building automation systems, DDC controllers, and data acquisition equipment.
Included with the transducer is a 3-valve manifold, providing a complete, ready-to-install assembly that simplifies field installation, allows for safe isolation and equalization during maintenance, and protects the sensing element during system startup and shutdown procedures.
Key Features
- Pressure range: 0–100 (PSI/inWC as applicable)
- Standard 4–20 mA analog output for broad controller compatibility
- Includes 3-valve manifold for easy isolation and equalization
- Designed for integration with building automation and DDC systems
- Reliable, repeatable pressure sensing for HVAC applications
- Simplifies installation with a complete transducer and manifold assembly
Applications
- Commercial HVAC pressure monitoring
- Building automation system (BAS) integration
- Air handling unit (AHU) and duct pressure measurement
- Hydronic system pressure sensing
- DDC and direct digital control systems
Product Specifications
- SKU: DP110100U3V4V
- Brand: Johnson Controls
- Output Signal: 4–20 mA
- Pressure Range: 0–100
- Manifold: 3-valve manifold included
