Mars 19551 Pump Potential Relay Overview
The Mars 19551 is a pump potential relay engineered to assist single-phase compressor motors during startup. Designed for 244/270V applications, this potential relay monitors the back-EMF (electromotive force) generated by the start winding and opens the start capacitor circuit at the correct moment — protecting the motor and ensuring smooth, reliable compressor operation cycle after cycle.
How a Pump Potential Relay Works
Potential relays are used in conjunction with start capacitors to provide the extra torque needed to bring a compressor motor up to operating speed. Once the motor reaches approximately 75–80% of its rated speed, the rising voltage across the start winding energizes the relay coil, opening the normally closed contacts and removing the start capacitor from the circuit. This prevents overheating and extends the life of both the capacitor and the compressor.
Key Features
- Rated voltage: 244/270V for broad compatibility across common single-phase compressor applications
- Pump potential relay design — ideal for hermetic and semi-hermetic compressor motor starting circuits
- Normally closed contacts open upon reaching the correct back-EMF threshold
- Compact, durable construction built for demanding HVAC and refrigeration environments
- Mars quality engineering for dependable, long-lasting performance
- Drop-in replacement suitable for a wide range of OEM applications
Typical Applications
- Single-phase hermetic compressor motor starting circuits
- Air conditioning and refrigeration systems requiring start capacitor assistance
- Hard-start and motor-protection applications
- Replacement of failed or degraded OEM potential relays
Why Choose Mars Relays
Mars has been a trusted name in HVAC electrical components for decades. Their relays are manufactured to tight tolerances, ensuring consistent pickup and dropout voltages that protect compressor motors and reduce costly callbacks. The Mars 19551 is a go-to choice for HVAC technicians who demand reliability in the field.
