Description
The Mars 20581 is a direct-acting, 3-way universal solenoid valve engineered for dependable general service applications in HVAC, refrigeration, and industrial environments. Built with a stainless steel body and NBR (Buna-N) seal, this valve delivers outstanding corrosion resistance and long service life across a broad range of compatible media.
Key Features
- 3-way universal configuration for versatile installation and flow-path control
- Direct-acting operation — no minimum pressure differential required
- Stainless steel body for superior corrosion resistance and durability
- NBR (Buna-N) seal compatible with air, water, and light oil
- Explosion-proof enclosure for use in hazardous location environments
- Compact 1/4″ NPT port size for easy integration into existing piping systems
Specifications
- SKU: 20581
- Valve Type: 3-Way, Direct Acting, Universal
- Port Size: 1/4″ NPT
- Voltage: 120VAC
- Cv Rating: 0.25
- Pressure Range: 0–50 PSI
- Compatible Media: Air, Water, and Light Oil
- Body Material: Stainless Steel
- Seal Material: NBR (Buna-N)
- Enclosure Type: Explosion Proof
Applications
- HVAC and refrigeration control systems
- Compressed air and pneumatic circuits
- Water and light oil flow control
- Hazardous location installations requiring explosion-proof rated components
- General-purpose industrial fluid control
The explosion-proof enclosure makes the Mars 20581 an ideal choice for installations in classified hazardous areas where flammable gases or vapors may be present. The 0–50 PSI operating pressure range and 0.25 Cv flow coefficient make it well-suited for precise, low-flow control in demanding service conditions.
