Description
The Regal H847 motor is a high-performance three phase motor built for demanding industrial and HVAC applications. Delivering 5 horsepower at 3450 RPM, this motor operates on 208–230 or 460 Vac three phase power, providing reliable high-speed operation for heavy-duty equipment. Its Y56HZ frame and open drip proof enclosure ensure proper ventilation while protecting the motor, and ball bearing construction delivers smooth, long-lasting performance. With a rigid base, 7/8" x 2 5/16" shaft, and reversible rotation, the H847 motor is designed for flexible installation and dependable service in a wide range of industrial and commercial systems.
Key Features:
-
5 HP three phase motor for industrial and HVAC applications
-
Operates on 208–230/460 Vac three phase power
-
3450 RPM single speed operation for high-speed performance
-
13.4–13.2–6.6 amp draw
-
Y56HZ frame size for standard mounting compatibility
-
Open drip proof enclosure for motor protection and ventilation
-
Ball bearing construction for smooth, reliable operation
-
Rigid base mounting for stability
-
7/8" x 2 5/16" shaft for secure connection
-
Reversible rotation for flexible installation
