Description
The Regal H853V2 motor is a heavy-duty three phase motor engineered for continuous duty industrial and HVAC applications. Delivering 1 1/2 horsepower at 1725 RPM, this motor is designed for dependable, long-term operation. With a 56H frame, open drip proof enclosure, and ball bearing construction, it provides durability and efficient cooling. The built-in automatic overload protector and high service factor make it well suited for demanding environments requiring consistent performance.
Key Features:
-
1 1/2 HP motor designed for industrial and HVAC continuous duty applications
-
Operates on 460/200-230 Vac, three phase power
-
1725 RPM single speed operation for reliable performance
-
Amperage ratings of 2.8 amps at 460V and 5.0–5.6 amps at 200–230V
-
1.15 service factor for added durability under load
-
56H frame size for standard industrial mounting
-
Open drip proof enclosure for effective ventilation
-
Ball bearing construction for long service life
-
Automatic overload protector for enhanced motor safety
-
Built for continuous duty operation in demanding conditions
