Regal Rexnord – LEESON 110088.00 1″ 2-Way 7.0Cv 24V 0-10Vdc Non-Spring Return Zone Valve

Description

Overview

The Regal Rexnord – LEESON 110088.00 is a 1-inch, 2-way modulating zone valve designed for precise flow control in hydronic heating and cooling systems. Engineered for commercial and residential HVAC applications, this valve combines a 7.0 Cv flow coefficient with a 0–10 Vdc modulating control signal, delivering accurate, proportional flow regulation in response to building automation and control systems.

Key Features

• 1-inch pipe connection for straightforward integration into standard hydronic piping
• 2-way (2W) valve configuration for reliable supply or return line installation
• 7.0 Cv flow coefficient for optimized flow capacity and system balance
• 24V operating voltage — compatible with standard low-voltage HVAC control systems
• 0–10 Vdc modulating control signal for proportional, precise flow adjustment
• Non-spring-return (NONS/R) actuator — valve holds last position on power loss
• Designed for use with building automation systems, DDC controllers, and modulating thermostats

Application

This zone valve is ideal for hydronic heating and chilled water cooling systems where modulating control is required. The non-spring-return design is well suited for applications where maintaining the last valve position on power interruption is preferred, reducing unnecessary actuator wear and energy consumption during brief outages.

Specifications

• SKU: 110088.00
• Brand: Regal Rexnord – LEESON
• Valve Size: 1 inch
• Valve Type: 2-Way (2W)
• Flow Coefficient (Cv): 7.0
• Supply Voltage: 24V
• Control Signal: 0–10 Vdc (modulating)
• Actuator Type: Non-Spring Return (NONS/R)
