Description
The Schneider Electric (Square D) BDL36030 is a heavy-duty 3-pole, 30-amp circuit breaker engineered for dependable overcurrent and short-circuit protection in commercial and industrial electrical distribution systems, including HVAC equipment panels and power distribution boards.
Product Overview
Part of Square D’s trusted PowerPact B-Frame I-Line series, the BDL36030 is designed to protect downstream equipment — including motors, compressors, air handlers, and other HVAC loads — from damaging overcurrent conditions. Its robust thermal-magnetic trip mechanism provides both overload and instantaneous short-circuit protection, making it a go-to solution for HVAC contractors and electrical professionals.
Key Specifications
- Amperage Rating: 30A
- Number of Poles: 3-Pole
- Voltage Rating: 600V AC
- Frame Series: PowerPact B-Frame (I-Line)
- Brand: Schneider Electric / Square D
- SKU / Part Number: BDL36030
Features & Benefits
- Thermal-magnetic trip mechanism for dual-mode overcurrent protection
- 3-pole design ideal for three-phase HVAC and commercial electrical systems
- I-Line plug-on design for fast, tool-free installation into compatible panelboards
- Compact B-Frame footprint saves valuable panel space
- Reliable Square D engineering trusted by HVAC and electrical professionals worldwide
- Suitable for protecting motors, compressors, and other HVAC electrical loads
Applications
- Commercial HVAC electrical panels and distribution boards
- Motor and compressor branch circuit protection
- Industrial and light commercial power distribution
- Retrofit and replacement in existing Square D I-Line panelboards
