Description
Utica-Dunkirk 30071 2-Way Valve Assembly with Motor Actuator
The Utica-Dunkirk 30071 is a complete 2-way characterizable control valve (CCv) assembly engineered for reliable hydronic and HVAC system flow control. Featuring stainless steel trim for enhanced durability and corrosion resistance, this assembly pairs a 1/2″ NPT valve body with an integrated motor actuator — delivering a ready-to-install solution for commercial and residential heating and cooling applications.
The non-spring-return actuator provides 45 in-lb of torque and supports On/Off and Floating control modes, making it highly versatile across a wide range of building automation and zone control applications. Dual-voltage compatibility (24 Vac / 24 Vdc) ensures seamless integration with standard low-voltage control systems. An included auxiliary switch enables end-of-travel feedback signaling for enhanced system monitoring and sequencing.
Key Features
- 2-way characterizable control valve (CCv) design for precise flow regulation
- Stainless steel trim for superior corrosion resistance and long service life
- 1/2″ NPT connection for easy installation in standard piping systems
- Flow coefficient: Cv 1.2
- Non-spring-return motor actuator — maintains last position on power loss
- 45 in-lb torque output for reliable valve actuation
- On/Off and Floating control modes for flexible system integration
- Dual-voltage operation: 24 Vac / 24 Vdc
- Auxiliary switch included for end-of-travel feedback and system sequencing
Specifications
- SKU: 30071
- Brand: Utica-Dunkirk
- Valve Type: 2-Way CCV (Characterizable Control Valve)
- Trim Material: Stainless Steel
- Connection Size: 1/2″ NPT
- Flow Coefficient (Cv): 1.2
- Actuator Type: Motor, Non-Spring Return
- Torque: 45 in-lb
- Control Modes: On/Off / Floating
- Supply Voltage: 24 Vac / 24 Vdc
- Auxiliary Switch: Included
Applications
- Hydronic heating and cooling systems
- Fan coil unit control
- Zone valve applications
- Building automation and DDC control systems
- Chilled water and hot water coil control
